We provide ONU&OLT&SFP&Media convertor
PON Interface: 1 GPON BOB (Class B+/Class C+) Application: FTTH(Home),FTTO(Office), FTTB(Building) Optical Interface: SC/UPC Connector LAN Interface: 1x 10/100/1000Mbps auto adaptive Ethernet interface Operating Temperature: 0℃~+50℃ Power Supply: DC 12V/0.5A Power Consumption: <3W Wavelength: TX: 1310nm, RX: 1490nm
Certification: ROHS/ ISO9001 /CE Warranty: 1 Year
EPON OLT is a high integration and medium capacity cassette EPON OLT designed for operators’access and enterprise campus network.
It follows the IEEE802.3 ah technical standards and meets the EPON OLT equipment requirements of YD/T 1945-2006 Technical requirements for access network——based on Ethernet Passive Optical Network (EPON) and China telecom EPON technical requirements 3.0. EPON OLT series possesses excellent openness, large capacity, high reliability, complete software function, efficient bandwidth utilization and Ethernet business support ability, widely applied to the operator front-end network coverage, private network construction, enterprise campus access and other access network construction.
The OLT provides 4 downlink 1.25G EPON ports, 8 * GE LAN Ethernet ports and 4*GE sfp optical for uplink. The height is only 1U for easy installation and space saving. It adopts the advanced technology, offering efficient EPON solution. Moreover, it saves a lot cost for operators for it can support different ONU hybrid networking.
Multi-sourced SFP package with dual LC/PC receptacles; Single mode dual fibers transmission Up to 20~80Km with 9/125μm SMF; AC coupled for Rx and Tx side Two temperature ranges: 0°C to +70°C for commercial level, -40°C to +85°C for industrial level; operates at data rate 1.25Gbps; Complies with MIL-STD-883/GR-468 Complies with lots of brands of switch such as cisco h3c……. Can be with or without DDM
10/100/1000M adaptive fast Ethernet optical Sfp Media Converter is a new product used for optical transmission via high-speed Ethernet. It is capable of switching between twisted pair and optical and relaying across 10/100/1000Base-TX to 1000Base-FX network segments, meeting long-distance, high-speed and high-broadband fast Ethernet workgroup users’ needs, achieving high-speed remote interconnection for up to 100 km’s relay-free computer data network. With steady and reliable performance, design in accordance with Ethernet standard , it is particularly applicable to a wide range of fields requiring a variety of broadband data network and high-reliability data transmission or dedicated IP data transfer network, such as telecommunication, cable television, railway, military, finance and securities, customs, civil aviation, shipping, power, water conservancy and oilfield etc, and is an ideal type of facility to build broadband campus network, cable TV and intelligent broadband FTTB/FTTH networks.
